How to use NX CAM 2D with DWG File - Step#5 Finish Countor and 2 Chamfer in 1 Operation.

File Download in video - https://drive.google.com/open?id=1DRM... NX CAM 2D Basic(with Dwg) Contents. 1. 2D CAM Setting :    • How to use NX CAM 2D with DWG AutoCAD File...   1. Open/Import DWG(AutoCAD) File 2. Start Manufacturing 3. Set MCS, Clearance, Fixture Offset 4. Workpiece(part,blank,check) 5. Tool Setting T01_10mm EM for Rough T02_10mm EM for finish T03_CenterDrill 3.15/8mm T04_TwistDrill 8mm T05_Chamfer T06_FaceCutter_40 from Tool_Library. T07_FaceCutter_50 Rough. T08_Ball_2mm_engrave 6. Operation List (All S1000 F100) 6-1.FaceMill Semi_finish(0.2)/finish -    • How to use NX CAM 2D with DWG AutoCAD File...   6-2.CenterDrill G99 G81 Z-2. R5. 6-3.PeckDrill G99 G83 Z-23. R5. Q3. 6-4.Pocket_Area Pre_Drilling_point -    • * How to use NX CAM 2D with DWG AutoCAD Fi...      • * How to use NX CAM 2D with DWG File  - St...   6-5.Contour_Area Semi_f(0.2)/finish 6-6.Chamfer In/Out side with one operation. 6-7.Engrave "NX CAD / CAM" 7. Simulation for verify Tool Path. Make IPW. 8. Postprocessor with Default 3axis_Mill 9. Edit/Make Default 3axis_Mill as Metric Insert G54, G99 in Canned Cycle. 10. Output Workoffset (G54~G59) 11. Register in Postprocessor List. 12. Register Post Builder Library. 13. Make/Use Custom Template.
