MechDesigner 14 - Tutorials - Part 3 - Calculate Cam-Coordinates- send to to SOLIDWORKS

This is Part 3 of a series of tutorials videos to help you get started with MechDesigner 14. This tutorial transfers Cam-Coordinates from a Cam we have modelled already - see Part 2 below, to a SOLIDWORKS cam blank. We use the Cam-Data we transfer from MechDesigner to cut the cam surfaces. The cam is perfectly smooth, to create a consistent Cam Mate in an Assemble. The Cam is normally manufactured from the CAm-Data. You can also export the Cam-Data as TXT or STEP file/. As well as Points, you can use BiArcs, which maintain tangency around the cam. BiArcs are more suitable for NC programming. See also: Part 1: Add a Slider-Crank -    • MechDesigner 14 - Tutorial - Part 1 - Add ...   Part 2: Model a Rotating Cam -    • MechDesigner 14 - Tutorials: Part 2 - Add ...
