0499: Carico Elettronico SIGLENT SDL1030X-E

► $2 for PCB Prototype(Any Color): https://jlcpcb.com/ ► Support me on Patreon:   / pieraisa   ► Forum: https://mylothehack.altervista.org/fo... ► Website: https://mylothehack.altervista.org/ ► Complete Video List and Sources download for patrons: https://mylothehack.altervista.org/op... Posted from San Francisco, CA Il video ha una piccola parte introduttiva sul principio di funzionamento dei carichi elettronici. Poi viene fatta una recensione dello strumento SIGLENT SDL1030X-E, che lavora fino a 300W di potenza, con illustrazione delle sue caratterisitche e test con un alimentatore da banco in tutte le modalità previste. Questo strumento risulta indispensabile per chi opera nel mondo della progettazioni alimentatori, amplificatori. ► Caratteristiche SDL1020X (Single channel ): DC 150 V/30 A, total power up to 200W 4 static modes / Dynamic mode: CC/CV/CR/CP CC Dynamic mode: Continuous, pulsed, toggled CC Dynamic mode: 25 kHz, CP Dynamic mode: 12.5 kHz CV Dynamic mode: 0.5 Hz Measuring speed of voltage and current: up to 500 kHz Adjustable current rise time range: 0.001 A/us~2.5 A/us Min. readback resolution: 0.1 mV, 0.1 mA Short-circuit, Battery test, CR-LED mode, and factory test functions 4-wire SENSE compensation mode function List function supports editing as many as 100 steps Program function supports 50 groups of steps OCP, OVP, OPP, OTP and LRV protection External analog control Voltage, Current monitoring via 0-10 V 3.5 inch TFT-LCD display, capable of displaying multiple parameters and statessimultaneously Built-in RS232/USB/LAN communication interface, USB- GPIB module (optional) Waveform trend chart and easy-touse file storage and call functions Includes PC software: Supports SCPI, LabView driver ►Specifications Input Ratings (0~40 ℃ ) Input voltage 0~150 V Input current 0~5 A 0~30 A Input power 300W Input Resistance greater than 200 kΩ Battery Measurement Battery Input: 0.5~150 V; Max Measurement: Capacity=999 AH Resolution=0.1 mA;Time Range=1 s~24 H Interface Built-in RS232/USB/LAN communication interface, USBGPIB module (optional) Dimensions 256 * 115 * 410 (WxHxD mm) Display 3.5 inch TFT-LCD display, capable of displaying multiple parameters and statessimultaneously
