HVAC: Bray Series 70 Actuator Valve Installation (4 Pipe Fan Coil Unit) FCU Bray Valve Replacement

HVAC: Bray Series 70 Actuator Valve Installation (4 Pipe Fan Coil Unit) FCU Bray Valve Replacement / Actuator Valve Troubleshooting / Actuator Valve Installation / Actuator Valve Replacement / Bray Series 70 / Chilled Water Actuator Valve / Hot Water Actuator Valve / York Air Handler Actuator Not Working / Bray Actuator Valve Not Opening / Bray Actuator Valve Not Closing / Bray Controls Series 70 Actuator Valve / Bray Series 31 Valve / Bray Series 31 Butterfly Valve Installation Series 70 Industrial Electric Actuator (Industrial Electric Actuators) The Bray Series 70 Electric Actuator provides a rugged, compact industrial actuator solution to a wide range of quarter turn applications including butterfly valves, ball valves, and dampers. Available in torque outputs from 800 to 18,000 in-lb (90 to 2033 Nm), these actuators mount directly to Bray and other industry standard butterfly valves without the need for brackets and linkages. The manual declutchable override handwheel is standard on all Bray Series 70 actuators, providing end user convenience in installation, commissioning and service. On/Off and modulating models are available in 24, 110 and 220 VAC. The standard enclosure is NEMA 4x and IP65 rated with an industrial polyester finish, making the Series 70 the ideal choice for cooling tower valves and other outdoor applications. The advanced Servo Pro or Servo NXT modulating control card assures compatibility with virtually any analog control signal used in today’s building automation and temperature control systems. Decades of Bray's proven success in electric actuation, combined with innovative engineering, has produced the Series 70 electric actuator. The Series 70 features on/off or modulating control and offers many advantages over other actuators including: 1. UL, CSA and CE certification of most units 2. Wiring directly to the terminal strip without interference from other components 3. Simple and unique manual override handwheel system 4. Lowest profile and lightest weight actuator on the market 5. Simple finger or screwdriver adjustment of travel limit cams without interference from other components 6. Highly visible valve status display on most units (Heartbeat) Series 70 Design Features: Designed like a junction box, the Series 70 offers by far the easiest access to terminal block wiring, cam adjustments and switch installation. Therefore, the time required for field startup and adjustment is greatly reduced, and maintenance can be performed with assured ease and safety. Thanks for watching! Email: JumperManTech@Gmail.com Follow me on Instagram! @JumpRmantech
