Q.What is NOT gate ? Definition, Symbol, truth table and applications of NOT gate ?

‪@seconds.1M‬ Welcome to my channel Q.What is NOT gate ? Definition, Symbol, truth table and applications of NOT gate ? A NOT gate is a logic gate that inverts the digital input signal. For this reason, a NOT gate is sometimes is referred to as an inverter (not to be confused with a power inverter). A NOT gate always has high (logical 1) output when its input is low (logical 0). Conversely, a logical NOT gate always has low (logical 0) output when the input is high (logical 1). The logical symbol for a NOT gate is shown below: If the input binary variable of a NOT gate is considered as A, then the output binary variable of the gate will be Ā. As the symbol of not operation is ( – ) bar. If the value of A is 1. then Ā = 0 and in the opposite if the value of A is then Ā = 1. Truth tables list the output of a particular digital logic circuit for all the possible combinations of its inputs. #physics #basics #notgate #definitions #electronic Thanks for watching #like #share #comments Subscribe for more ❤️
