Atrump Manual Knee Milling Machine ~ Model: K2VS Mill w/ Options Brand-New on floor in Utah Whse.

MACHINERY CONSULTANTS INC BILL WILSON JR. 1390 W. 200 S. Salt Lake City, UT 84104 Ph: 801-531-9500 Fx: 801-531-9555 E mail: mci@machineryconsultants.com website: www.machineryconsultants.com General specifications are approximate, subject to verification Atrump Manual Knee Milling Machine ~ Model: K2VS Mill ( NEW) Standard's & Specification: Table Working Area: 9” X 49” Longitudinal travel (X-axis): 36” Cross travel: ( 12" ) (12” less ¼” for DRO Scale on rear of Table) Z axis quill travel: 5” Knee travel (manual): 16” Quill diameter: 3.375” Spindle nose to table top (D) 0.75”-16.75” Load capacity: 820 lbs. Spindle taper: R8 Spindle Speeds in rpm speed range: 70 to 4200 rpm with High/Low gear Transmission of spindle & motor: Timing Belt, Variable speed Range’s Spindle center to column front surface: 6.875” to 27.875” Ram Travel: (front to back movement) 12” Head Swiveling Capacity: Swivel (left/right): 90 degree Tile (front/back): 45 degree Motor – Main Drive Motor info: Spindle motor/max torque: 3 HP (Standard) KVA rating: 4 KVA, 15 amps Coolant pump (optional): 1/8 HP Lubrication pump: one shot lube with manual crank handle Power requirement: 4 KVA, 3 Phase 208-230 voltage ( can accept 440 Volts also ) Length X Width X Height (LXWXH): 77” x 65” x 82” Net Weight: 2,600 lbs. . Items Included in Price of Milling machine: Align – X Axis Table Power feed Unit, Pre-Installed Sino Brand 2 Axis on X and Y DRO, Pre-Installed Safety Folding Handles for table left, right & cross axis, included 1 Shot Oil - Lube - System (with Clear Tank for High-visibility)  Neoprene Way Covers, Halogen Work Light – Installed 3 HP Spindle Motor, R8 Spindle Taper / request 220 or 440 Volts  0 - 4200 RPM spindle speeds/ High & Low Range (low back gear)  Hardened & Ground with turcite-B coating guide way,  C7 Double nut precision acme lead screws for high accuracy & long lasting  FC30 Meehanite Casting main frame with annealed & stress relieved for long term reliability  Anti rust chromed quill, super precise, smooth & accurate  Standard Neoprene way covers on all three axes  Tool box & Tools  Precision APEC class7 spindle bearing to ensure spindle run out within 0.0002  Auto-1 shot lube pump system for Oil Lubrication on xyz axis  Sino Brand DRO-2-Axis – X & Y Digital Readout Unit – Pre-Installed  Align X – Axis Table Power Feed Unit – Pre Installed on Table  Built - in Quartz Halogen work light (Long arm type) /collet tray **** Operations & Maintenance Manual Optional Accessories: available upon request: R8 collet Sets, many brands in stock, 58 pc. Clamp kit, mill vises, Tooling for spindle, Keyed & Keyless Drill chucks, angle plates, power drawbar, additional Power feed units for Cross & Knee axis. Bill Jr., Technical Sales Manager, Director of Operations Bill Wilson Jr. of Machinery Consultants Inc. 1390 West 200 South Salt Lake City, Utah 84104 Office Phone 801-531-9500 Office Fax 801-531-9555 E Mail for mci@machineryconsultants.com Our website: www.machineryconsultants.com For Used & New Machine Tools & Any Machine Tool Accessories We also sell & offer Replacement Parts ~ Proudly Serving & Servicing the Machine Tool Industry Since 1963
