XRHRobotStar: Fully automated X-ray inspection system

Fast – Shortest cycle times for high volume inspection The XRHRobotStar is an ultra-fast inspection system for all kinds of small to medium parts that can work with up to 225kV. Reference systems for the inspection of aluminum casting parts exist in the automotive industry. By building cluster solutions consisting of several cabinets the throughput can be increased even more. The basic functionality is that an (un)loading robot on the outside handles the incoming parts from the customer defined conveyor and distributes the inspected parts to the next processes, while on the inside a robot with a mounted C-Arm, housing the X-ray components inspects the pre-programmed test-positions. The retrieved images are checked by the Xplus Automated Defect Recognition (ADR) for critical flaws or other user defined critera. In case of a mixed production the system can have different sequences for every part type. The parts will be recognized through an Data Matrix Code (DMC). Reliable – Count on market-proven and certified image quality Experience brilliant images through the Xplus image enhancement system. Sophisticated image enhancement tools like real-time noise reduction and image enhancement with the LiveFilters, resolution and contrast verification, multiple measurement tools, overlays and many more result entitle our solutions for the most demanding inspection jobs. The VisiConsult ADR can be taught without any further programming knowledge by the supervisor. For archiving purposes, a variety of platforms are offered: DICONDE, overlayed X-ray images, databases and many more can be used. Together with an offline inspection station the operator can review scrap parts without interrupting the in-line process. Flexible – Comprehensive X-ray component choice The X-ray components include the detector, X-ray tube, generator, HV-cable, cooler and flat panel detector. All components can be chosen based on customer preferences and inspection job requirements. The VisiConsult application engineers will do a comprehensive consulting to suggest the best setup.
