Dial Indexing Assembly System

This system is a dial based assembly system to complete assemblies at a rate of 1,600 parts per hour. The production rate is achieved by processing assemblies 2-up on a 4.5 second cycle. The assembly dial features 8 stations, each with 2 part nests. Parts are fed to the system via vibratory bowls, elevating hoppers provide extended run time and a lower bulk part load height. A Fanuc robot is utilized to load the barrels as well as to offload complete assemblies. The system assembles the plug and cap to the main barrel utilizing dual bowl escapements and servo driven part loading to the dial nests. There are also two leak test stations that check for plug leaks Jewett Automation is a systems integrator specializing in the Design and development of automated manufacturing and assembly systems. Our experience ranges from indexing cam-driven assembly systems, to robotics and Vision, to high speed continuous motion. We are committed to providing a high level of personal attention to every one of our customers. Do not think of Jewett Automation as your Automation Equipment Supplier, we are your automation partner. Visit our website at www.JewettAutomation.com, give us a call at 804-344-8101 or send us an email over at Sales@JewettAutomation.com #Robotics #JewettAutomation #Fanuc @Jewett Automation @FANUCRoboticsInc
