1/43 RC Truck Build - Bench Top Driver - Files Now Available

Build your own bench trip driver from Stock SCX24, Ascent 18 of FCX24 Electronics. Very inexpensive build and lots of fun on the workbench. 00:00 - Introduction and Overview 02:50 - Soldering the Motor 03:48 - Chassis Assembly 05:39 - Steering Assembly 09:58 - Truck Bed Prep 11:30 - Wheels and Tires 13:50 - Truck Bed Assembly 15:57 - Bumpers 16:67 - Final Assembly 19:15 - Test Drive! Free files Maker World - https://makerworld.com/en/models/1043... Thingiverse - https://www.thingiverse.com/thing:692... You will need: Leftover RC ESC/Receiver Combo from SCX24 and the AS01 servo or aftermarket servo such as the EMax. Other electronics of similar size should work as well, such as those from the Redcat Ascent 18 or the FMS FCX24. Four 2x5mm bearings. Width of 2.5mm is what I use, but 2mm should also work. N20 motor with transmission. I use the 12v 100RPM motors for good slow speed control. Very helpful when backing a wagon. Two M2x10mm screws to hold front wheels 26 M1.4x6mm screws to attach chassis, bed, body, etc 1 M1.4x8 screw for steering plastic servo horn Optional simulated motor can be attached with glue or sticky tack Tires. Rims are provided for LDARC X43 tires and also cheap toy tires found on AliExpress. I used the toy tires labeled as 1/43 size. They have a 15mm rim size, though it is often hard to tell from the descriptions. They are often sold in lots of 20 or more. Battery. The original SCX24 battery is too large. I use a 200mah battery measuring 20x33x10mm. Wire with connecter for ESC to motor Source Files for Remix. Many thanks to the original creators. Truck Body - https://www.thingiverse.com/thing:353... Simulated Wood - https://makerworld.com/en/models/5990... Simulated Engine - https://makerworld.com/en/models/6810... Wagon files coming soon. Enjoy!
