How to Measure Squareness & Perpendicularity with Laser Alignment | Pinpoint Laser Systems

In this video, Pinpoint Laser Systems demonstrates how to precisely measure the squareness and perpendicularity of a machine tool or industrial equipment using the Pinpoint Microgage laser alignment system and 90-Line right angle accessory — delivering a complete surface profile and squareness statistics in a single measurement pass. This squareness measurement setup uses the following components: Laser Transmitter: Produces a straight beam of reference light along one edge of the machine, establishing the primary measurement baseline. 90-Line Right Angle Accessory: Uses an internal optical pentaprism to generate a precise right angle beam off the incoming laser reference line, creating a second reference line along the perpendicular edge of the machine. Digital Receiver: Picks up the laser beam position and sends real-time readings to the display unit for immediate feedback during measurement. Microgage Display and Pinpoint Capture Software: Records and stores readings at each measurement location, generates a full profile of the measured edge, displays angular deviation at each point, and provides a complete statistical summary of the overall squareness of one edge relative to the other. The measurement process demonstrated in this video: Position the laser transmitter along the first edge of the machine and take reference readings at two locations. Bring the receiver around the corner to the perpendicular edge and take a series of readings along its full length. Pinpoint Capture generates a profile of the edge with angular deviations at each measurement location and an overall squareness statistic relative to the reference edge. This method is ideal for: Machine tool squareness and perpendicularity verification Z-axis alignment on CNC machining centers Indexing system and flange squareness checks Press and forming equipment perpendicularity measurement Gantry and bridge squareness verification Any application requiring precise right angle measurement between two surfaces or machine axes Made in the USA | Free Technical Support | Custom Mounting Solutions Available Speak with an Alignment Engineer: (978) 532-8001 Learn More: https://pinpointlaser.com/application... Request a Free Alignment Report: https://pinpointlaser.com/resources/a... Schedule a Free Demo: https://pinpointlaser.com/resources/a... #SquarenessMeasurement #Perpendicularity #LaserAlignment #MachineAlignment #PrecisionMeasurement #PinpointLaser #90Line #CNCAlignment #MachineToolAlignment #IndustrialMeasurement
