R289 Solenoid valve

R 289 valve is a 2/2 diaphragm valve that completes the range of the R Series Double 90°. The inlet is a BSPP ¾’’ male thread, usually supplied with filter and white flow regulator (up to 10 lt/min); either, it is possible to change just the flow regulator or to switch them with a check-valve 20 mm diameter. The two outlets are 90° oriented, with quick coupling 8 mm connections. Flow reducer or check-valve can be installed upon request. The valve's internal diameter is 11 mm with flow rates exceeding 40/45 lt/min. Wide variety of custom setups available: three different types of membrane (NBR, LSR, EPDM), coils tension from 12V to 240V, choice of electrical connections (faston, unipolar cables, bipolar cables), plastic or iron bracket. The valve comes with all the R SERIES certifications, including CE, food approvals (NSF, Wras, KTW) and electrical ones (ENEC or UL request).
