Shear force and bending moment diagrams example #1: single point load

This engineering statics tutorial goes over an example of a simply supported beam with a single point load. In order to draw the shear force diagram (SFD) and bending moment diagram (BMD), we first need to draw a free body diagram (FBD) of the whole structure to solve for the reactions. Then we take a few virtual cuts in the regions on each side of the point load to be able to draw the SFD and BMD. If you found this video helpful, please consider supporting my work on Patreon:   / engineer4free   Looking for more statics tutorials? Check out all of the videos that I made: YouTube:    • Dynamics   Website: https://www.engineer4free.com/statics Looking for practice problems with solutions? I also created a whole set of fully solved statics problems with step-by-step hand calculations: https://www.engineer4free.com/statics... Looking for software? I highly recommend checking out SkyCiv. They make a full suite of online structural analysis software and tools that are useful for both students and professionals, including calculators for beams, trusses, frames, moment of inertia and more. It’s great for checking your work: https://bit.ly/skyciv-e4f Lastly, don’t forget to subscribe on YouTube and join the Engineer4Free mail list: Subscribe:    / @engineer4free   Mail List: https://www.engineer4free.com/newsletter Thanks for watching, I hope it helps!
