How to Terminate an RG6 F-TYPE (SNS1P6U) Coaxial Compression Connector - The TSOC™ Minute (ep. 2)

BUY ONLINE: https://www.lineartechnologies.ca/tmr... RG6 F TYPE SNAP AND SEAL COMPRESSION CONNECTOR RED RING, 50PCS/PKG (SNS1P6U) For More Tutorials Visit: http://www.TSOC.com How to Terminate an RG6 F-TYPE Coaxial Compression Connector Materials Required: CT-RG596SS: Coaxial Compression Tool (SNS1P6U) MST-RGA: Coaxial Cable Prep Tool MST-502: Side Cutter TMRG-6CONSSU: RG6 F-Type Coaxial Compression Connector FT4-RG6WH2: RG6 Coaxial Cable Step 1: Cut the specified length of RG6 Coaxial Cable (FT4-RG6WH2) and insert ¾" into the Coaxial Cable Prep Tool (MST-RGA). Rotate in one direction 2-3 turns. Step 2: The Coaxial Cable will be scored in 2 stages. Remove the 1st stage exposing the Centre Conductor. Remove the 2nd stage exposing the Foam Insulation and Steel Braid. Fold back the Steel Braid towards the Coaxial Cable. Step 3: Insert the Coaxial Cable into the RG6 F-Type Coaxial Compression Connector (TMRG-6CONSSU). Ensure the Centre Conductor is kept straight while firmly pushing until the Foam Insulation reaches the edge of the Compression Connector. Step 4: Insert the Compression Connector into the cavity of the Coaxial Compression Tool (CT-RG596SS). Squeeze the handles together until the ratchet system unlocks and remove the terminated Compression Connector. Step 5: Trim the Centre Conductor using the Side Cutters (MST-502). Inspect to make sure the Compression Connector is firmly secured to the Coaxial Cable. Step 6: Repeat steps 1 through 5 to terminate the opposite end to complete the RG6 Coaxial Cable Assembly. Keywords: TMRG-6CONSSU-50 RG6 F TYPE SNAP AND SEAL COMPRESSION CONNECTOR RED RING, 50PCS/PKG CT-RG611SS RG6 F TYPE SNAP AND SEAL COMPRESSION CONNECTOR RED RING, 10PCS/PKG (SNS1P6U) F-Type Snap & Seal
