Single Plane 4-Run Balancing Using Motionics iPad Rotor Balancing Kit and iRotorBalancer App

This this is quick demo video of balancing a single plane rotor using 4-Run method with Motionics iPad Rotor Balancing Kit and iRotorBalancer App. For 4-Run method, only acceleration signal from an accelerometer is required. The process consists of 4 testing runs: 1) measuring original vibration while the testing rotor is running, 2-4) placing a trial weight at 0°, 120° and 240° locations on the rotor and taking measurements respectively. Then correction weight can be calculated from the 4 measured vibration amplitudes. Using Motionics iPad Rotor Balancing Kit, a DAQ box mounted on the back of iPad continuously collects vibration signal from a piezoelectric accelerometer. iRotorBalancer App running on iPad processes incoming signal and computes vibration amplitude. The user only needs to tap a few buttons to capture vibration readings and the App does all the calculations. Hardware: Motionics iPad Rotor Balancing Kit Motionics iPad Rotor Balancing Kit turns an iPad into a rotor balancer and vibration analyzer. It is a purely iPad-based kit consisting of an iPad (optional), a 2-channel DAQ box, an industrial accelerometer and a laser tachometer. The kit comes with several apps for vibration analysis, overall vibration testing, and rotor balancing. The iPad iRotorBalancer app allows single-plane, 2-plane, 4-runs, and overhung balancing to meet different rotor balancing requirements. With just simple tapping and typing, anyone can be an expert in rotor balancing using this package. The iPhone/iPad VibraTestPro App makes the kit a full vibration analyzer with time, domain, and frequency domain analysis. The kit also comes with the iVibraMeter App for iPad which can be used for a quick overall vibration tests of multiple common machines such as pumps, motors, spindles, etc. with rapid PDF report generation capability. Software: iRotorBalancer App v1.29 iRotorBalancer App: an iPad application that collects vibration information through accelerometers and optical sensors to balance rotating machinery in single-plane and two-planes. Single-Plane balancing using the Vector-Method (Amplitude & Phase Measurements) Single-Plane balancing using the Four-Runs-Method (Amplitude Measurement) Two-Plane inbound balancing using the Influence Coefficients Method (Amplitude & Phase Measurements) Two-Plane overhung balancing (Amplitude & Phase Measurements) Real-time signal waveform and FFT spectrum display Automatic select 1x peak amplitude and phase Polar plot to show graphic location of trial and correction weights Convenient calculator to estimate trial weight Angular mass distribution calculator to help distribute mass if correction weight location is not available Weight removal calculator to help determine drill bit size and depth for material removal Interactive permissible residual imbalance determination to quickly evaluate balancing quality PDF report with test information, balancing data, machine vibration before and after balancing, map location, pictures from library or camera, signature and notes Local report manager to save test reports PDF report export via AirDrop, Email, wireless printing and cloud storage (Dropbox, Google Drive, OneDrive, etc) For more information, please visit Motionics website: Motionics iPad Rotor Balancing Kit https://motionics.com/product/ipad-ro... iRotorBalancer App https://motionics.com/product/irotorb... ABOUT MOTIONICS Motionics, LLC was established in February 2011 in Austin, TX, and develops new technologies for advanced vibration analysis of rotating machinery. Another expertise of Motionics is educational products including software and hardware for engineering and technical applications. Motionics also provides innovative industrial solutions in the form of tablet-based software (applications) along with custom-designed hardware for vibration analysis.
