Oscillator circuit for 8051 Microcontroller

Lecture Series on 8051 Microcontroller Lecture9: Oscillator circuit for 8051 Microcontroller When we have to work with the 8051 microcontroller IC, we have to make the basic connection of power supply and after that the most important connection is crystal Oscillator. This circuit is the heart of the system. We have to select a specific frequency of crystal oscillator 11.0592 MHz. 33 pF capacitors for the same circuit is required. Relation between crystal oscillator frequency and Machine cycle frequency is explained in this video. Reference: 1) The 8051 Microcontroller & Embedded Systems by M. A. Mazidi & J. G. Mazidi & Mckinlay, Pearson Prentice Hall. 2) The 8051 Microcontroller Architecture, Programming and Applications by Kenneth J. Ayala , Penram International Publications. You can complete the 8051 Microcontroller course by clicking on the link:    • Introduction to 8051 Microcontroller (Man ...   You can also complete the Digital Electronics course by using the link:    • Combinational Logic Circuits   If you want to learn more about 8051 Microcontroller you can visit my website. Link: https://satishnikam007.wordpress.com/...
