Siglent SDS 1202X-E Serial Diagnostic Basics From a Layman

Edit: Video got distorted in upload apparently, but it still gives the general idea. http://www.siglentamerica.com/USA_web... The above link is to the official manual from Siglent. Please follow all recommended safety procedures. There are situations where using the ground clips on the probes can short things through your scope via your building's grid. Although it's not likely when working with lower voltages, it takes an insanely small amount of current to stop a person's heart. I take no responsibility for your actions. I'm a hobbiest at best. I'm not an EE. I'm sure some of the terminology I use is not optimal and maybe even wrong, but using the techniques in the video i've been very successful in improving serial communications on various peices of industrial equipment and brought a number of production machines back from the dead. I welcome feedback as it will only serve to improve my understanding. I'll probably do a more production quality version down the road.
