Animation of a "flying saw"

This nice animation shows how a "flying saw" operates in principal. The sawing unit is accelerated on a linear guide parallel to the conveyor belt until the speed is synchronized with the conveyor belt and the position of the saw blade corresponds to the requested material length. The linear speed of the sawing unit is controlled and adjusted every millisecond to match the speed of the conveyor belt during the sawing process. This guarantees that the soft material is not compressed or stretched by the saw blade. The result is a perfect linear cut without any fraying and it is done independently of any changes in the speed of the material flow. As soon as the complete material width is cut, the movement of the sawing unit on the linear guide is decelerated, reversed, and moved back into its starting position. MACS motion control units of zub machine control AG are the perfect solution for actual any application requiring drive synchronization based on position, velocity or CAM - profiling linked to a master drive.
