Concentric Cable - What’s it Used For?

What is the cable supplying your 100, 80 or 60 amp cutout fuse in a domestic property? Concentric and split concentric cable explained - aluminium line conductor and a copper combined neutral and earth conductor in concentric cable. The split concentric cable has and aluminium line conductor and copper neutral and copper earth insulated from each other. We see how a concentric cable can be mistaken for a SWA (steel wire armour) cable coming into the bottom of a domestic cutout. We also highlight the equipment with in a meter box and common sizes of cables. TN-C-S TN-S T = Terra N = Neutral C = Combined S = Separate Electrical UK Wiring 🕕 Time Stamps - Cut to the action 🕕 00:00 - Concentric cable is feeding your cutout 00:30 - Intake position equipment 00:47 - Whats does TN-C-S stand for 01:27 - 100 amp switch 02:32 - Concentric cable 03:03 - Combined copper neutral and Earth 03:33 - Inside the cutout 04:37 - Solid link 06:12 - Split concentric cable 🔔 Subscribe for more free electrical training videos https://youtube.com/c/GSHElectrical?s... 🔵 How to Make Off an Armoured Cable - SWA Cable with an Amour Slice    • How to Make Off an Armoured Cable - SWA   Videos are training aids for City and Guilds (C and G) and EAL courses Level 1, 2, 3 plus AM2, AM2S and AM2E. You can follow me day by day on Facebook, Instagram, Twitter and TikTok lookout for "GSH Electrical”. ▶️ FACEBOOK   / gshelectrical   ▶️ INSTAGRAM   / brihzmraygdtmjmdb9lunqodmevqsbddki3qpq0   ▶️ TWITTER   / gsh_electrical   ▶️ TikTok https://vm.tiktok.com/ZMRBLFdhe/ #GSHElectrical #Electricaltrainingvideos #electricalwiring #cable #tncs
