Sketch Entities: Ellipses & Slots | SOLIDWORKS 2020 BEGINNER | Chapter 01: Lesson 06 | CSWA COURSE

Subscribe for more completely FREE SolidWorks lessons at: https://bit.ly/2GNqkgb In SOLIDWORKS 2020 there are two curved, closed loops sketch entities to help with sketching. They are the ELLIPSE tool and the SLOT tool. Although not often used, they are very efficient to use in the right situations. In this lesson you will learn the 2 Ellipse options available, the standard ellipse and the partial ellipse. You will also learn how to use the 4 slot tool options which are the straight slot, centerpoint straight slot, 3-point arc slot, and the centerpoint arc slot. This video is Chapter 01: Lesson 06 in my CSWA (Certified SolidWorks Associate) course which is completely FREE on YouTube. I only ask in return is that if you please like the video and subscribe to the channel to show your support. TOPICS COVERED • How to access the Ellipse and Slot tools • Standard Ellipse tool • Ellipse additional options • Pre-setting dimensions using the Ellipse tool additional options • Partial Ellipse tool • How to modify an Ellipse • Straight Slot tool • Slot tool additional options • Centerpoint Straight Slot tool • 3-point Arc Slot tool • Centerpoint Arc Slot tool • How to modify a Slot
