Appion TEZ8 Proper Use Tips

The TEZ8 Vacuum Pump was the first AC/R vacuum pump designed from the ground up for service work. Technicians have used the TEZ8 since 2009 to conquer even the toughest evacuation jobs and have reported up to a 10x time savings. Looking to get the most out of your TEZ8? Following the best practice tips in this video will help keep your pump and evacuations running fast! 🔧 Use the Multi-Port Input to connect hoses with ⅜”, ¼” and ½” fittings. The remote exhaust allows the technician to ventilate the workspace when working in clean rooms, small mechanical rooms or with toxic refrigerants. 🔧 Record a baseline before beginning the evacuation by connecting a vacuum gauge directly to the pump. 🔧 Always remove as many restrictions as possible in order to not restrict the flow to the pump. Common restrictions include valve cores & core depressors. 🔧 Connect directly to the vacuum pump for the fastest & most reliable evacuation. Use large diameter, vacuum-rated hoses on both sides of the system. 🔧 Vacuum gauges should always be connected as far from the vacuum pump as possible for an accurate measurement. Measure the system, not the pump. 🔧 Always start the pump with one of the caps off. 🔧 Working in a cold environment? Keep the TEZOM Oil Cartridge warm before installing it into the pump for easy start up even as cold as -40ºF/C! 🔧 Monitor the oil visually and with a vacuum gauge to know when it needs to be changed. When the evacuation has stalled, the oil is saturated with contaminants and should be changed. 🔧 If you’re doing an on-the-fly oil change, use a cloth under the oil supply tube to catch any oil spillage. 🔧 Monitor the Debris Tube for any contaminants or debris pulled from the system. 🔧 Clean and relubricate the Debris Tube & Input Tree O-Rings as necessary. Using High-Vacuum Grease is recommended, but Dielectric Grease is also vacuum-rated and can be used as a substitute. 🔧 Flush the TEZ8 after a job is complete, especially after working on extremely wet or burnout systems. Watch the TEZ8 Flush Video for detailed instructions:    • TEZ8 Self-Flush Procedure   🔧 Always remove a cap and return the pump to atmospheric pressure when shutting it off. Questions? Contact our support team: support@AppionTools.com or 303-937-1580 ---- About Us: Appion is Applied Innovation. We never stop challenging ourselves to develop smaller, lighter, and more innovative tools for HVAC/R technicians. Appion’s solutions for fast Refrigerant Recovery, Evacuation and Measurement include: G5Twin Recovery Machine, TEZ8 Vacuum Pump, appION Wireless Digital Gauges, and MegaFlow Vacuum-Rated Tools. Visit us at AppionTools.com!
