Retrieving Data from a Register File with SystemVerilog: Addressing Race Conditions

Discover how to effectively retrieve data from a register file using SystemVerilog while addressing race conditions in your testbench design. --- This video is based on the question https://stackoverflow.com/q/72155913/ asked by the user 'asimtot' ( https://stackoverflow.com/u/13392361/ ) and on the answer https://stackoverflow.com/a/72156006/ provided by the user 'toolic' ( https://stackoverflow.com/u/197758/ ) at 'Stack Overflow' website. Thanks to these great users and Stackexchange community for their contributions. Visit these links for original content and any more details, such as alternate solutions, latest updates/developments on topic, comments, revision history etc. For example, the original title of the Question was: Retrieving Data from Register File (Unpacked Array) Also, Content (except music) licensed under CC BY-SA https://meta.stackexchange.com/help/l... The original Question post is licensed under the 'CC BY-SA 4.0' ( https://creativecommons.org/licenses/... ) license, and the original Answer post is licensed under the 'CC BY-SA 4.0' ( https://creativecommons.org/licenses/... ) license. If anything seems off to you, please feel free to write me at vlogize [AT] gmail [DOT] com. --- Retrieving Data from a Register File with SystemVerilog: Addressing Race Conditions Managing data efficiently is crucial in hardware design, and when using a register file in SystemVerilog, it can become challenging if not done correctly. In this guide, we will explore a common issue encountered while retrieving data from a register file, specifically focusing on a race condition in the testbench that prevents the correct data from being retrieved. By the end of this post, you'll understand both the problem and the solution, ensuring your register file operates as it should. The Problem: Understanding the Register File Design The code provided in the question outlines a basic design of a register file with the following features: A clock signal (clk) that regulates the operation of the register file. Two control signals: M_we for write enable, and M_re for read enable. An address signal (M_add) to specify which register to read from or write to. A data signal (M_wd) for the data to be written, and an output signal (M_rd) for the data read from the register. Example of the Register File Module [[See Video to Reveal this Text or Code Snippet]] In your testbench, you attempted to write to the register file and then read from it to verify that the write operation was successful. However, during simulation, you detected that the expected value was not reflected in the desired output. Instead, you encountered undefined behavior (xxxx). The Cause: Race Condition in the Testbench The issue arises due to a race condition in the testbench. In the current setup, the signals are not driven synchronously with respect to the clock (clk). When the design reads (M_re) and writes (M_we) are not synchronized with the clock edge, they do not reflect the intended operations at the correct times. Key Issues Race Condition: The M_we signal is not maintained at a high value long enough for the RegisterFile to capture it correctly. Improper Signal Assignment: Signal assignments should utilize nonblocking assignments (<=) and be driven in response to the positive edge of the clock. The Solution: Synchronous Signal Driving To resolve this issue, you need to synchronize the testbench inputs with the clock. This means utilizing the @(posedge clk) construct and ensuring to use nonblocking assignments. Updated Testbench Code Here’s how you can refactor your testbench: [[See Video to Reveal this Text or Code Snippet]] In the refactored testbench: Synchronous Assignments: We update the control signals at the positive edge of the clock. Clarity and Reliability: Now the signals will behave as expected, allowing the design to correctly read and update values in the register file. Conclusion Understanding how to manage signals in your hardware designs, especially in testbenches, is essential for achieving accurate simulations. By synchronizing the control signals with the clock and using proper assignment methods, we can effectively eliminate race conditions and validate the behavior of our design. Next time you're working with a register file in SystemVerilog, remember these principles to ensure your testbench yields the desired results. Happy coding!
