Drawing eight-shaped line 3

Input: the small gear shaft. Center of the pink slider traces an eight-shaped line. The pink slider has a lower pin that is placed in holes of the yellow and orange gear, so the slider moves together with the gears. The pink slider also has a rhombus-shaped part. It ensures that the slider moves along the eight-shaped slot of the beige guide plate. The straight slot of the beige guide plate is for mounting the slider. This mechanism is used in braiding machines:    • Видео   A mechanism of the same function: Taffy puller    • Taffy puller 1   Inventor files of this video: https://www.mediafire.com/file/gwfkit...
