Impel® Pumper – Union FPD

Traditionally, the Union Fire Protection District chose the Quantum cab, Detroit Diesel engine, and a two-stage pump. For the first time with their new 1,000-gallon pumper, they chose the Impel cab, 450 hp Cummins engine and a single stage pump. For an overall perspective on the scene, the department continues to go with a top mount pump panel. This gives the operator a visual on both sides of the truck for effective scene operation. Showing off the local high school pride, the apparatus features the school’s theme and colors. The SCBA doors are latched with recessed D-ring handles. CHASSIS Chassis: 70” Impel® cab with 10” raised roof Seating capacity: 5 Overall height: 10’ 4” Overall length: 35’ 3” GVW rating: 53,800 lb Safety: Side Roll and Frontal Impact Protection Front axle: TAK4® Independent Front Suspension, 22,800 lb Rear axle: Meritor RS30-185, 31,000 lb Engine: Cummins L9, 450 hp, 1,250 torque BODY Material: Aluminum Shelving: Adjustable, up to 500 lb Doors: Lap Pump: Waterous, 1,500 gpm Tank: 1,000 gallons Foam system: Husky™12 Foam cell: 60 gallons Job No: 33755 Dealership: MacQueen Emergency Group
