Kirchhoff’s Current Law (KCL) – Junction Rule Statement: Kisi bhi junction (node) par incoming current ka sum = outgoing current ka sum hota hai. Formula: \sum I_{in}=\sum I_{out}- Matlab: Current kabhi accumulate nahi hota, jo current junction me aata hai wahi junction se nikalta hai. Example: Agar ek junction par 3 A aur 2 A current enter kar rahe hain, aur ek branch se 4 A nikal raha hai, to bachi hui branch se 1 A nikalna hoga. 2. Kirchhoff’s Voltage Law (KVL) – Loop Rule Statement: Kisi bhi closed loop me total voltage rise = total voltage drop hota hai. Formula: \sum V=0-
