Annotation Scaling

Get a free trial of this dwg-based CAD software on http://www.graebert.com. With Annotative Scaling, ARES Commander 2016 introduces a great improvement for dimensions, text, hatches, and blocks. Much more than a cost-effective alternative to AutoCAD for CAD in dwg, ARES Commander 2016 brings your productivity to the next level with new XtraTools and a unique concept: The Cross-device CAD Experience. ARES Commander is the first CAD Software running on Windows, Mac & Linux + now Android (and soon on iOS) with the new ARES Touch. For more than 30 years now, Graebert has been renown as an innovator and ARES Commander is the third generation of our CAD technologies after FelixCAD and PowerCAD. ARES Commander 2016 concentrates the best of our CAD technologies that are currently used by more than 7 Million of professionals around the World. 0:00 Annotation Scaling in ARES Commander 2016 0:33 Dimensions 1:03 How does the annotative scale work? 1:46 “Not Annotative” style 2:15 Self-adapt ability of dimensions with annotative scaling 2:26 “AnnoStyle” 2:46 Viewports 3:47 Annotative scaling property 5:00 CNTRL key to add more scales 5:17 Deleting scale 5:46 Viewport scale can be locked 6:39 PAN (pressing the mouse wheel) 6:57 Text in annotative style 7:26 Activating the Annotative Scaling parameter 7:38 Learn more about ARES Commander #CADSoftware #ModernCAD #DesktopCAD #DWG #2DCAD #2DDrawing#CADFeatures
