LESSON -02 | PROJECT -01 | HOW TO CREAT PLAN DRAWING IN TEKLA STRUCTURE

LESSON -02 | HOW TO CREAT PLAN DRAWING IN TEKLA STRUCTURE To create a plan drawing from Tekla Structures: 1. Open the model in Tekla Structures. 2. Go to the "Drawings" menu and select "Plan". 3. Choose the desired plan view (e.g., Floor Plan, Foundation Plan). 4. Select the components to include in the plan (e.g., columns, beams, walls). 5. Adjust the drawing settings as needed (e.g., scale, annotation, dimensions). 6. Click "Create" to generate the plan drawing. Alternatively, you can also use the "Quick Drawings" tool: 1. Select the components to include in the plan. 2. Go to the "Quick Drawings" toolbar and click on the "Plan" button. 3. Choose the desired plan view and adjust settings as needed. 4. Click "Create" to generate the plan drawing. Tips: Use the "Filter" tool to select specific components to include in the plan. Use the "View" tool to adjust the view orientation and create a custom plan. Use the "Annotation" tool to add text, dimensions, and other annotations to the plan. Additionally, you can also use the "Plan
