Dragonlink 7km FPV Distance Record with Narrative - Skywalker GoPro

7km flight out and back again (14km round trip). Just testing the maximums on my setup. I have alot to do as far as cleaning up the electronics on this baby. Any of you guys have any ideas, based on what you see? Is my live video feed Bad? Good? Average? FPV Setup: ----- In the AIR: ---- Aircraft: Skywalker with 1900mm Wing (bevrc.com $130) Propulsion System: Ogar/Skywalker Power System HC3516-1350 from readymaderc.com ($110) Includes: Castle Creations Thunderbird 54A Esc Himax 3516-1350 350 watt Brushless Outrunner Motor APC 9x6e Prop Onboard Servos: 1 Hitec HS-5485HB Digital Servo (from local hobby shop - for panning GoPro) ($25) 4 Hitech HS-65HB Karbonite Gear servos for rud,elev,and 2 ailerons (ebay $88) RC Receiver: DragonLink UHF RC System Tx ($100 of $269 Tx and Rx combo) Electronics Battery: Parkzone 3s 1300mAh 15C LiPo (local hobby shop $30) (powers Hornet OSD, Video TX, Futaba RX, FY31-AP) Motor Battery: Gens ace 5500mah 3S1P 11.1V 25C Lipo battery pack (hobbypartz.com $41) (powers esc and Himax Brushless Motor above) Video Tx and Antenna: 1.3G 800mW tx for 12V system ($50 bevrc.com) Omni: 1.3 GHz Skew-Planar Wheel Whip Antenna (RHCP) ($33 readymaderc.com) Feiyu Tech FY31-AP Flight Stabilizer trade edition with GPS, Current Sensor and Hornet OSD ($290 bevrc.com) GoPro Hero HD cam for HD Recording of flights ($200 ebay) 16GB SDHC Flash Card for GoPro ($15 ebay) BEV-KX181H-NTSC (Made by Sony - Live video Feed Cam) ($82 bevrc.com) Misc parts and glues (carbon fiber, ply, etc.) $100 FLYING WEIGHT 5lb 9.5oz =TOTAL COST IN AIR: $1294 ---- On the GROUND: ---- RC Radio: Futaba FP-8UAP PCM 1024 72mHz transmitter ($200 used) Long Range UHF System: DragonLink UHF RC System (attached to Futaba radio $169 of $269 combo) RC Tx Aftermarket Battery Pack: 8 cell 9.6V 2500mAh high capacity battery pack for Futaba tx ($28 ebay) Tripod: Manfrotto MKC3-H01 (Target $50) Rx Antennas (2): Directional: Helical 1.3GHz 9.5dBi RHCP (urbandrones.com $70) Omni: 1.3 GHz Skew-Planar Wheel Whip Antenna (RHCP) ($33 readymaderc.com) Video Receivers (2): 1.3gHz Rx on 12V system ($30 ea. (x2) bevrc.com) Diversity: Eagle Eyes FPV Station with Plastic Case (readymaderc.com $90) Ground Station Battery: Zippy 3s 5000mAh 20C LiPo (powers video goggles, both 1.3gHz video RXs, Eagle Eyes - ebay $25) Video Goggles: FatShark Dominator video goggles ($300 bevrc.com) Flight Camera Video Capturing: EasyCAP USB 2.0 Video Audio AV Capture ($7 ebay) (I use my laptop to capture live video, but did not include cost here) Misc parts, tripod, wires, connectors, solder, velcro, servo programmer, etc. ($150 easily) =TOTAL COST ON GROUND: $1182 =TOTAL COST: $2476 (Yikes!) FPV Flying Experience: Priceless!
