JUPITER E Cable and Phase identification MADE SA

Pre-identification device for de-energised LV and MV cables JUPITER E FUNCTION JUPITER E is for use on all types of de-energised LV/MV cables for :  Cable identification  Identifying short-circuit (SC) and open-circuit (OC) conductors  Short-circuit continuity (SC) and open-circuit continuity (OC) THE BENEFITS JUPITER E has all the same functions as JUPITER+, but with the following new features :  Simplified ergonomics : for OC identification, direct reading of the phases with the test probes thanks to a different colour code for each probe  Continuity and identification of neutral using direct reading  Detection of the direction of the current generated by the transmitter : a colour code is used to identify the transmitter position relative to the Rogowski coil orientation  Drastically reduced weight and volume  Optimised accessory storage PRINCIPLES OF USE JUPITER E is composed of a transmitter and a receiverwhich can be used on a locked out, short-circuited andearthed network. The transmitter is connected in a substation, on a MV switchgear cabinet or LV electrical panel using 3 injectionclamps (excluding screens and equipotential bonding). The receiver is used to pre-identify the cable, check continuity, and identify open-circuit and short-circuit phases Transmitter Receiver • LiFe PO4 6.4 V - 1.5 Ah battery • Max. autonomy : 7 h continuous • Also runs on 230 V AC (on charge) • 205 x 40 x 110 mm • IP 54 • 4 AA 1.5 V alkaline batteries • Max. autonomy : 2000 measurements • 170 x 400 x 95 mm • IP 54 Total weight 8.7 kg Site : https://www.made-sa.com Facebook :   / madeofficiel   Linkedin :   / made-sa
