BUILDING a DIY HiFi AMP KIT - Elekit TU8500 pt.1

In this first part of the series, Nick will be walking you through the Elekit TU-8500 Tube Pre-amplifier Kit with Phono Stage. Showing you everything included with the kit and then starting to put it together. https://www.hificollective.co.uk/kits... Please subscribe so you don't miss the rest of this project. ========== Elekit's DIY pre-amplifier with Phono Stage offers amazing performance in such a small package. Featuring a precision phono stage RIAA equalization (CR not NF) supports both MM and MC cartridges. Two low noise OPAMPS (NJM2068DD) are used in the phono stage. The OP-AMPS are socket mounted making OP-AMP switching easy. Two 12AU7 (ECC82) tubes are used in the line amp stage. The gain is switchable (Approx 1x to 3x). Reduced hum/background noise circuitry includes a low flux leakage R-core transformer, a FET ripple filter for B-power and the tubes are powered by the DC power supply. Sufficient space has been provided on the PCB for the substitution of larger coupling capacitors facilitating upgrading parts. The kit supports 4 different AC input voltages. 100Vac, 115Vac, 200Vac and 230Vac so it can be used anywhere in the world. It is an ideal complement to the TU-8200 power amp, sharing the same size footprint. Produced by www.TenToh.com
