3ds Max - Setting references with single blueprint image [Tutorial]

A 3DAZ Studio original content. Let's find out how hard it is. The blueprint scale in this video is not 1:1 However, In this tutorial we will adjust the scale inside 3ds Max to match 1:1 scale. The idea of this video was not using spline technology inside 3ds Max, but using the polygons technology. However, If you want to follow the spline editing path you still can generate a surface with the proper splines modifiers which we might do in future videos. Timeline: 00:00 - Intro 00:35 - Car base 00:45 - Car wheelbase 01:03 - Car width 01:27 - Blueprint editing 02:52 - System unit setup 03:05 - Dimensions box 03:31 - Center to world 04:06 - 4 sides for references 04:26 - Blueprint material 04:56 - Unwrapping 06:41 - Detaching references 07:32 - Freezing references 08:05 - Overlapped references 08:24 - Create custom grid 08:59 - Line tool 09:23 - Fix low resolution refs. 09:39 - Tracking blueprint 10:35 - Correct top ref. mapping 11:54 - Spline tracking in CAD vs Max 12:19 - Surfacing the spline shape 12:33 - Bad topology 13:12 - Splines shapes behavior 14:07 - 3ds Max spline limitation 14:42 - Including side mirrors 15:04 - Extrude edges in opposite direction 15:33 - Freezing UV maps 15:39 - Relax UV maps 18:10 - Render UVW template 19:02 - Finalization & cleaning refs. Link to the 3ds Max scene: https://www.mediafire.com/file/ucpkz5... Honda Accord 03/04/05 have the same external body. In 2005 model they changed the side mirrors a little bit. 👉👉To support our channel:   / 3daz
