Installation - Aidoo Daikin Sky Air / VRV Wi-Fi Controller

Device to manage and integrate Daikin units remotely from the Cloud. Online control with the “Airzone Aidoo” App (available for IOS and Android). Wireless WiFi connection. Externally powered by the indoor unit. Features: • Control of the parameters of the unit. • Communication errors detection. • Temperature and operating mode time schedules. • Multi-user and multi-session. • Port for integration via Modbus protocol. For further information about our products, go to airzonecontrol.com 1) Perform the assembly following the next step: a. Screw attachment b. Double-sided adhesive attachment 2) Disconnect the Daikin indoor unit. 3) Connect the Aidoo to the terminals of the indoor unit using the supplied cable, X35A and P1 P2. 4) Power the indoor unit. Check the LEDs (see Self-diagnosis section). 5) Disable the Setback function using the Daikin controllers (BRC1E52A7, …) for a proper operation of the Airzone system. Service Settings ► Field Settings ► 1e-2-01. If you have any doubt, please check the Instruction manual Daikin BRC1E52A7. 6) Download the app and follow the steps bellow for its setting. Access the support section to see the user manual.
