Voltage Divider Bias Configuration in Hindi | Voltage Divider Bias Configuration with example

voltage divider Bias configuration full concept of voltage divider Bias configuration. Voltage Divider Bias Configuration in Hindi | Voltage Divider Bias Configuration with example Voltage Divider Bias Configuration in Hindi Voltage Divider Bias Configuration with example of using a negative supply off of the emitter resistor, like two-supply emitter bias, this configuration returns the emitter resistor to ground and raises the base voltage. So as to avoid issues with a second power supply, this base voltage is derived from the collector power supply via a voltage divider. The bias template is shown in Figure 5.4.1. Here the common emitter transistor configuration is biased using a voltage divider network to increase stability. The name of this biasing configuration comes from the fact that the two resistors RB1 and RB2 form a voltage or potential divider network across the supply with their center point junction connected the transistors base terminal as shown. This voltage divider biasing configuration is the most widely used transistor biasing method. The emitter diode of the transistor is forward biased by the voltage value developed across resistor RB2. Also, voltage divider network biasing makes the transistor circuit independent of changes in beta as the biasing voltages set at the transistors base, emitter, and collector terminals are not dependant on external circuit values Voltage Divider Bias Circuit: Circuit Operation – Voltage Divider Bias Circuit, also known as emitter current bias, is the most stable of the three basic transistor bias circuits. A voltage divider bias circuit is shown in Fig. 5-22(a), and the current and voltage conditions throughout the circuit are illustrated in Fig. 5-22(b). It is seen that, as well as the collector resistor (RC), there is an emitter resistor (RE) connected in series with the transistor. As discussed already, the total dc load in series with the transistor is (RC + RE), and this total resistance must be used when drawing the dc load line for the circuit. Resistors R1 and R2 constitute a voltage divider that divides the supply voltage to produce the base bias voltage (VB). #voltagedividerbiasconfiguration
