MCQ'S on slotting (slotter) machine with solution through diagram & videos .... Prof. Sudhir Thakre

A Slotter Machine is another machine tool similar to a Shaper or a Planer Machine A slotter machine is a machine tool in which material is removed for producing desired shapes. It is used for producing Machining cylindrical surfaces and flat surfaces. Slotter Machine Main Parts or Construction: Slotter Machine consists of following Main Parts: Base Column Saddle Cross-slide Rotating table Ram and Tool head assembly Ram drive mechanism Feed mechanism Slotter Machine Mechanism: Following are the slotter machine ram drive mechanism: Whitworth quick return mechanism Variable speed reversible motor drive mechanism Hydraulic drive mechanism Feed Mechanism: In a slotter, the feed is given by a table either by hand or power. The slotter table may have three movements: Longitudinal feed: If the table is fed perpendicular to the column toward or away from its face is known as a longitudinal feed. Crossfeed: If the table is fed parallel to the face of the column is known as crossfeed. Circular feed: If the table is fed by rotating the table about the vertical axis is known as a circular feed. Types of Slotter Machine Operation: The following operations are performed in a slotter machine are: Machining cylindrical surface. Machining flat surface Machining irregular surface and cam machining Machining slots, keyways, and grooves.
