SUMINO 1900 TPU extrusion coating machine &TPU film casting machine

SUMINO 1900 TPU extrusion coating machine #tpufilmcastingmachine #tpufilmmakingmachine #hotmeltfilmextrusionmachine #TPUcoatingmachine #suminoextrusion #TPUextrusionlaminatingmachine #extrusionlaminatingmachine #extrusionlaminationmachine #tpufilmcastingmachine #TPUfilmmakingmachine Performance characteristics: This unit uses two plastic extruders to separately extrude the backing fabric and the adhesive, and compound them through the distributor; at the exit of the flat film "T" mold, it merges into a single flow flat film and evenly pours it on the base fabric. Under the action of the embossing cooling roller, the coating film and the base cloth are adhered firmly; after cooling, shaping, and trimming, it is rolled into a finished product. 1.The whole machine adopts frequency conversion speed regulation and advanced monitoring system to realize monotonous and group control linkage control, the control is accurate, stable, reliable, and the degree of automation is high. 2. The extrusion part adopts the co-extrusion type. Two specially optimized and specially designed extruders respectively extrude the back rubber fabric and the adhesive, which are compounded by the melt distributor, and merged into a single cast flat film at the exit of the die. Spread evenly on the base cloth, and the thickness of the film can be adjusted individually. 3.Using automatic temperature controller with PID adjustment, high temperature control accuracy. 4. The barrel heater is a cast aluminum belt air-cooled structure to reduce temperature errors. 5.Automatic feeding, double-station hydraulic quick screen change, mechanical device action pneumatic control, high degree of automation. 6.Double-station constant tension automatic unwinding, automatic correction, automatic cloth splicing device, realize non-stop roll change. 7. The trimming and sizing device is driven by a separate motor, and the cut is neat; it is reliable in use, and the edge material is automatically collected. 8.Before lamination, a hot roller is used to preheat and dry the substrate. 9.After compounding, the cold roll is cooled and shaped. 10.The embossing laminating roller adopts a forced water cooling structure. 11.The coiling is surface coiling; with automatic length fixing and cutting functions. use: The use of TPE, TPU, PE, EVA and other plastic environmentally friendly raw materials is used to co-extrusion and laminate the textiles, and the textiles do not need to be glued. This environmentally friendly adhesive will replace PVC and become the mainstream of industrial fabric adhesives. It is suitable for the compounding of base materials such as nylon silk, PP non-woven fabric, cotton cloth, Oxford cloth, mesh cloth, paper, plastic film, etc. In particular, the bonding of the substrates that are not easy to compound and firm with a single extruder is more firm. Unit composition: Special high-efficiency plastic extruder (two sets), double-station hydraulic screen changer, co-extrusion mold, mobile frame, double-station unwinding, preheating, compound machine, cooling and shaping, traction cutting, winding machine, electric cabinet The main technical parameters: Maximum extrusion capacity: 150/250kg/h Effective coating width: 1650mm Film thickness: 0.03-0.5mm Coating materials: TPU, TPE, PE, EVA, adhesive Substrate: PP non-woven fabric, nylon cloth, cotton cloth, paper, nylon silk, luggage cloth Mechanical line speed: 8-80m/min Installed capacity: 285KW Weight: 35t Sue International Business Development Department Manager Nanjing Sumino Extrusion Machinery Co.,Ltd Add: Kaituo Road No.11, Jiangning District, Nanjing, China. Tel: +86 025-51839686 Fax: +86 025-51839687 Mob: +86 177 1241 3069 Email: suqian@susumino.com
