2321258 Replacing Your Refrigerator Ice Maker Thermostat WP2321258, AP4370477, 1480168, PS2324100

Part number 2321258 can be found at http://www.pcappliancerepair.com/inqu... The ice maker thermostat determines the temperature of the ice maker. You may need to replace the ice maker thermostat if your refrigerator is not producing ice. For this repair you will need: quarter inch nut driver flat head screw driver Phillips head screw driver needle nose pliers loom elastic Today, Cherylin from Point and Click is here to guide you step-by-step through another Quick 'n Easy Repair: Replacing Your Refrigerator Ice Maker Thermostat (part number 2321258 ) in a Maytag (Whirlpool) Refrigerator. Part Number 2321258 replaces WP2321258, 1480168, AH2324100, EA2324100, PS2324100, AP4370477, 1709335ASM. Warning: Before starting any repair, always make sure that the appliance is completely disconnected from the power source by unplugging the appliance. Step-by-step how to instructions for replacing the Refrigerator Ice Maker Thermostat (part number 2321258) in a Maytag (Whirlpool) Refrigerator: 1. Open the freezer door. 2. Remove the ice maker assembly. 3. Unscrew the top two screws holding in the ice maker. 4. Unscrew the screw on the bottom. 5. Remove the ice maker. 6. Disconnect the wire harness. 7. Remove the shut off arm. 8. Remove the cover on the motor. 9. Remove the wire harness. 10. Remove the motor. 11. Remove the Phillips head screws. 12. Carefully pull off the motor housing. 13. Lift out the thermostat. 14. Replace the containers next to the thermostat. 15. Place your new retainers, press into place. 16. Place your new thermostat. 17. Put a dime size of loom elastic onto the thermostat. 18. Reassemble the ice maker, line up all the spindles and press it into place. 19. Replace the screws. 20. Turn the ice ejector so the end lines up with the motor. 21. Replace the three screws. 22. Replace the wire harness. 23. Replace the motor cover. 24. Replace the shut off arm. 25. Bring the ice maker back into the refrigerator. 26. Reconnect the wire harness 27. Replace the top and bottom screws. 28. Replace the ice dispenser. 29. Push it into place. This part also works with other manufactured brands including Whirlpool and Maytag. Visit PCAppliancerepair.com to find the part that works for your refrigerator! Get more Refrigerator repair help at http://www.pcappliancerepair.com/repa... Make sure to connect with us!   / pointclickap.  .   / pcapplrepair   https://plus.google.com/+pcappliancer...   / pcapplrepair     / pcappliancer.  . https://pcappliancerepair.wordpress.com/ Subscribe to our e-mail newsletter for more appliance repair help, new product news and more. Visit http://www.pcappliancerepair.com and enter your e-mail address in the subscribe box on the side. Please give us a like, and subscribe to our channel! If you have any questions, please feel free to leave a comment below!
