ICSE 10th Physics - Problem 8 - Copper loss in transformers

Title: Problem 8 - Copper loss in transformers Copper loss in transformers refers to the energy lost due to the resistance of the windings when current flows through them. It is a variable loss that increases with load and is calculated using the formula. Reducing copper loss improves transformer efficiency significantly. 🔌 What Is Copper Loss in Transformers? Definition • Copper loss is the electrical energy dissipated as heat in the primary and secondary windings of a transformer due to their resistance. • It is also called I²R loss, where: • = current through the winding • = resistance of the winding Formula • Units: Watts (W) • Occurs in: Both primary and secondary windings 📈 Why Copper Loss Is a Variable Loss • Depends on load current: As load increases, current increases, and so does copper loss. • Unlike core loss (iron loss), which is constant regardless of load, copper loss varies dynamically. 🌡️ Temperature Effect on Resistance • Resistance increases with temperature, which increases copper loss. ⚙️ Methods to Reduce Copper Loss • Use high-conductivity copper for windings • Optimize winding design to reduce resistance • Use larger cross-sectional area conductors • Improve cooling to reduce temperature rise • Operate near rated load to avoid excessive current 🔔 Like, Subscribe, and Share! Don’t miss more exciting physics content—hit the bell icon to stay updated on new lectures. Drop your questions or feedback in the comments below! Please, let me know if I made any mistake. 📱Connect with Me for More Physics Fun: • Telegram: Join my physics community for exclusive resources, discussions, and updates! – https://t.me/Hologram2dd • Instagram: Follow for bite-sized physics tips, behind-the-scenes content, and more! https://www.instagram.com/hologram.2d... • Facebook: Stay connected with my physics community and get the latest updates!   / 1mtykkbndu   Problem 1 -    • ICSE 10th Physics - Problem 1 - Car light ...   Problem 2 -    • ICSE 10th Physics - Problem 2 - Overloadin...   Problem 3 -    • ICSE 10th Physics - Problem 3 - Frequency ...   Problem 4 -    • ICSE 10th Physics - Problem 4 - Frequency ...   Problem 5 -   • ICSE 10th Physics - Problem 5 - Frequency ...
