Slice tool (AutoCAD 3D Tutorials)

In AutoCAD, the Slice tool is a feature that allows you to divide 3D objects into two or more parts along a specified cutting plane. It is a useful tool for creating sections or cutting through solid or surface objects to reveal internal details or create new geometry. To use the Slice tool, you select the object you want to slice and specify the cutting plane. The cutting plane can be defined by a 2D shape, such as a line, polyline, or closed shape. AutoCAD then divides the object into two separate parts, based on the intersection of the cutting plane and the object's geometry. The Slice tool provides options to control the behavior and results of the slicing operation. You can choose to keep or discard the original object, specify whether to create new objects from the sliced portions, or create a region or 3D solid from the intersection of the cutting plane and the object. The Slice tool is commonly used in various fields, including architecture, engineering, and product design. It allows you to examine the internal details of objects, create cross-sections for documentation or analysis purposes, or modify existing objects by removing or adding geometry. By combining the Slice tool with other tools and features in AutoCAD, you can perform complex operations. For example, you can slice a solid object and then use the resulting parts to perform other operations like extrusions, chamfers, or fillets. Overall, the Slice tool in AutoCAD provides a powerful way to divide 3D objects along a cutting plane. It offers flexibility in controlling the slicing operation and allows you to create precise cross-sections or modify objects to meet your design requirements.
