Introduction to the WavePro HD

This video introduces the Teledyne LeCroy WavePro HD oscilloscope. WavePro HD High-Definition oscilloscopes employ unique Teledyne LeCroy HD4096 technology to achieve 12-bit resolution at up to 8 GHz bandwidth, for the lowest noise and unmatched signal fidelity. Up to 5 Gpt of highly responsive acquisition memory gives more visibility into system behavior, and the exceptional analysis toolbox enables deep insight. Learn more: https://teledynelecroy.com/waveprohd/ Deeply Embedded Computing Systems Testing WavePro HD has unsurpassed capabilities to acquire the longest records at the highest resolution for the most comprehensive deeply embedded computing system (analog, digital, serial data and sensor) testing. Comprehensive low-speed serial data triggers and decoders, plus measure/ graph and eye diagram testing provide the best causal analysis. Power Integrity Testing WavePro HD's combination of high bandwidth and high resolution provides the capability to validate and debug all aspects of power supply, delivery and consumption - ensuring complete confidence. High bandwidth means accurate characterization of high-speed on-die effects such as ground bounce, while exceptionally low noise enables identification and root-cause analysis of low-level noise sources. Sensitive measurements such as rail collapse characterization can be made with complete confidence thanks to WavePro HD's high dynamic range and 0.5% gain accuracy. Serial Data Jitter and Noise Analysis WavePro HD 12-bit oscilloscopes bring the high signal fidelity of HD4096 technology to high-speed serial data analysis. 12-bit resolution, exceptionally low noise and 60 fs timebase jitter mean a low jitter measurement floor, for the most accurate serial data jitter and noise measurements possible. SDAIII CompleteLinQ provides the most complete set of serial data analysis tools available, and user-friendly QualiPHY options greatly simplify complex compliance testing. Electromagnetic Compatibility (EMC/EMI) WavePro HD 12-bit oscilloscopes' high sample rate and long memory combine with Teledyne LeCroy's dedicated EMC pulse parameter package to accurately characterize EMC test signals. Fast pulse rise times may require 2.5 to 4 GHz bandwidth at very high sample rates to ensure measurement confidence. WavePro HD provides the most accurate characterization using 20 GS/s sample rate, 12-bit resolution, and 0.5% gain accuracy. See all of our oscilloscopes here: https://teledynelecroy.com/oscilloscope/ Connect with us on Social Media   / teledynelecroy     / teledynelecroy     / teledyne-lecroy   Check out our blog https://blog.teledynelecroy.com/ Subscribe to our channel    / lecroycorp   #TeledyneLeCroy
