How to Connect and set analog time switch|Electreca

Analogue time switch: It works on a 24-hour analogue clock, The device comprises a clock, coil, contacts(NO and NC) and a battery for backup. The time clock has a trigger(pins) which activates the contacts. How the analogue time switch operates First, supply the timer with AC 240V, set the timer in the clock(sign) position and set the correct time of the day. Use the pins by pressing them inside to set the time on when and how long do you want the LIGHT to go on. There are 4 pins between an hour to hours. Each PIN is 15 minutes. Analogue timer switch is easy to use and to set DESCRIPTION OF THE TIMER Installation on DIN rail, surface or built-in (66x66 mm). Compact design and installation base with precuts for power supply through cable track or tube when installed on the surface. The front sphere is easy to program by movable trippers. Switch for manual control with three positions: automatic, permanent on/off. Models with a backup battery available (= 100 h). Faston Connections 6,3 x 0,8 mm for built-in mounting in the electrical cabinet door. Models Watch more videos here on how to clean a computer keyboard    • How To Clean Keyboard|Electreca   AVS connection    • How to connect Automatic Voltage Switcher|...   floatless level switch(controls water pump)    • Floatless Level Switch Connection Explained   VISIT MY BLOG FOR MORE CONTENT https://electrecasolutions.com/blog/ SOME AFFILIATE LINKS Analogue time switch https://amzn.to/39FF7VR camera i use(D5300) https://amzn.to/36v3rYH mic(shortgun)Comica CVM-VM20 Professiona https://amzn.to/2MtWgJt Disclaimer: ELECTRECA is a participant in the Amazon Associates Program, an affiliate advertising program designed to provide a means for sites to earn advertising fees by advertising and linking to www.amazon.com Contact me here electreca.workshop@gmail.com Follow me on Twitter https://x.com/elektreca Whatsapp/call: +254786927909 Mpesa: 0717377423 Paypal: ssengendod@gmail.com
