FPGA project 02 Part1 - Multiplexer to LEDs

Part1 - Verilog tutorial and Modelsim testbench The second easiest FPGA project... A multiplexer, or mux, is a basic digital circuit used to drive one of the multiple inputs to one output by using a select bus. This Verilog tutorial contains a parameterizable Multiplexer to LEDs Verilog project that can be implemented on any Intel(Altera) FPGA board (at least 3 switches and 1 LED required). This practical Verilog tutorial for beginners will show you the following: How to design a synthesizable Verilog multiplexer with 2 input Nbit ports s (N=4 default) and 1 select bit. The mux output is connected with the LEDs on an FPGA development board How to create a Verilog testbench for the Multiplexer to LEDs project How to create a Modelsim project and to test your digital circuit modeled with Verilog Part2 of this project will show you how to program an FPGA using the DE1-SoC development board that has an Intel/Altera Cyclone5 5CSEMA5F31C6N FPGA. You can find it here    • FPGA project 02 Part2 - Multiplexer to LEDs   If you want to easily master Verilog for FPGA design and verification I recommend you the popular Udemy course "Verilog HDL Fundamentals for Digital Design and Functional Verification" Udemy https://bit.ly/3EakPQJ. #verilog #FPGA #verilogtutorial #FPGAtutorial #FPGAprojects
