Rookie to Rocking it: A Sheet Metal Masterclass in Alibre

Can you learn Sheet Metal in #Alibre in only 1 hour? Yes, you can. 🔥 In this video, we'll cover: 📌 Getting started with Sheet Metal parts 📌 Creating 3D geometries like a pro 📌 A deep dive into each tool's functionality 📌 Unveiling best practices for success 📌 Bonus: Converting solid models into Sheet Metal wonders So grab a cup of your favourite beverage - tea, coffee, or anything you fancy - and let's dive right in! Go on... Get it... I'll wait! P.S. You can find the parts shown in this video on the thread I made for it on the Alibre Forums 00:00 Intro 00:26 How to start a sheet metal part in Alibre 01:00 Sheet Metal Parameters 02:07 Base Features v. Editing features 03:28 Tab Base Feature 05:55 Moving on with the Flange Feature 06:30 Flange Feature - Alignment Options 10:36 Trim Side Bends 11:30 Flat Pattern 12:40 Leg Length Options 15:50 Advanced Tab 16:16 Corners Tab 17:40 Bend Only 18:15 Bend Angle 19:58 Width Offsets 22:18 Reverse Bend and Flage Direction Selection 23:23 Creating flanges that interfere only in the flat pattern 24:32 Troubleshooting with the Flat Pattern and Best Practices 26:26 Contour Command 27:07 Showing equations in sketch dimensions 27:45 Contour Command Options 30:24 Exploring Manufacturability in 3D vs Flat Pattern 34:17 Adding additional tabs 35:55 Sketched Bend 38:25 Closed Corner Command - Discussing Butt Welds in Sheet Metal 40:18 Dimple 43:03 Cuts and propagating to the Flat Pattern 44:04 Chamfer and Fillet in Sheet Metal 44:54 Convert to Sheet Metal 47:19 Unbend and Rebend
