UV Enlargers - Part01: A 100W UV light source

To really enjoy the previous discussed processes in this channel we need a reliable and safe enlarger so we can skip digital negatives and curve adjustment all together. We'll use an enlarger with a condenser at first and later we'll build a couple from scratch for analog and digital. And if time permits we'll go beyond that, imagine printing a cyanotype from your phone. The components in this project could be replaced by others of similar functionality. Here's a list of components for this build: 1) HS: heat sink, an old computer CPU one will do. 2) LED: 100W UV light COB 395NM 3) R: Resistor 50W 25 Ohm Aluminum Case 4) Power Supply from an old PC computer 5) VB: DC-DC Boost Converter, 6) TM: Relay Cycle Timer FRM01 7) Pot: 100K potentiometer 8) PB: Momentary Push Button Switch Normal Open 9) LN: Lens + Reflector + Fixed bracket for 100W LED 10) TG: Thermal Conductive Glue Please be safe when working with high voltages and protect your eyes from UV lights. Feel free to ask questions. You are welcome to join us on Facebook for more discussions: www.facebook.com/groups/alternative2 To participate help the research: https://paypal.me/AltResearch Have a great week and see you in the next video. #CHIBA #cyanotype #dichromate #bichromate
