Rectangular weir|| Rate of flow over rectangular weir || Expression for discharge|| Flow measurement

About this video: This video tutorial is all about flow over rectangular notch/weir in detail. Here we are going to derive an expression for discharge (Flow rate) over rectangular weir. The rectangular weir is a standard weir frequently used in irrigation channel system for measuring the discharge. It is simple to construct and easy to maintain. Rectangular weir may be fully contracted(end contraction ) using blade or suppressed (no end contraction). The discharge passing through notch or weir is estimated by measuring the head above the crest level. The head is measured above crest level. The head is measured in the upstream when the water surface is by using point gauge or hook gauge or in some cases by automatic water level recorder. Here we derive expression for discharge in two cases: i. Rectangular notch/weir with end contraction ii. rectangular notch/weir without end contraction Again we do considering velocity of approach and without velocity approach. To know all these and understand you have to watch this video. This channel publishes videos on civil engineering topics (Especially fluid mechanics). If you have any question regarding fluid mechanics then comment in the comment section below. IO will make a video tutorial so that everyone who visit this channel would gain knowledge on that. Before watching please like this video. After watching this video don,t forget to comment about this video in the comment section. Please Subscribe to this channel if you are student of civil engineering or interested in engineering or if you have completed engineering degree. About this channel: This channel publishes videos on engineering topics.This is "Competitive Engineers". You can use it to online study by watching video.If you are student who wants to gain knowledge on engineering subject matter then subscribe to my channel. My channel publish videos related to civil engineering topics or its subject matters. if that sounds like it could be helpful and useful for you, please join me. #CompetitiveEngineers #FluidMechanics #RectangularWeir For numerical problem on flow measurement:    • Fluid Mechanics I Conceptual problem I Num...
