GLOBALTEK® - Rotary Table With In-feed Table And Unscrambler Attachment

The Globaltek rotary tables can be used to unscramble product and feed a conveyor, also as a buffer space to accumulate product until the downstream conveyor is ready for additional product or collect. Accumulating rotary tables are designed to collect filled containers from a filling line to prevent slowdowns by quickly removing the finished product from the conveyors during operation. Can be set for clockwise and counterclockwise rotation. Accumulating rotary tables are designed to collect filled containers from a filling line to prevent slowdowns by quickly removing the finished product from the conveyors during operation. Can be set for clockwise and counterclockwise rotation. MAIN FEATURES MADE IN USA WITH 100% UL CERTIFIED COMPONENTS STAINLESS STEEL OPEN FRAME OR ENCLOSED CABINET ADJUSTABLE LEVELING PADS DISK THICKNESS 1/8” (11 GAGE) COUNTER AND CLOCKWISE BODINE DC DRIVE FOR ROTATION SPEED CONTROL TECHINCAL DATA BODINE DC MOTOR, 3/16 HP, 6 RPM, 350LB/IN MACHINE ELECTRICAL REQUIREMENTS: 115 VOLTS / 1 PH / 60 HZ ROTARY TABLE STANDARD SIZE: 36”, 48”, 60” (OTHER SIZES UPON REQUEST) FLOOR TO DISK: 35” TO 39” ADJUSTABLE GUIDE RAIL HEIGHT: 0” TO 5” SPEED: 0 TO 8 RPM OPTIONAL FEATURES TOOL-LESS BOTTLE ORIENTING GUIDES INFEED TABLE FOR HAND PACKING APPLICATIONS OR TO PUSH LOAD CONTAINERS ONTO ROTATION DISC LOCKING CASTERS DUAL GUIDE RAILS 4” STAINLESS STEEL GUIDE RAILS TRANSFER PLATE FOR SMOOTHER CONTAINER TRANSITION (SIDE OR STRAIGHT MOUNT) WARRANTY 12 MONTHS (LIMITED WARRANTY)
