Welcome to our PSpice tutorial! In this step-by-step video, we will simulate and analyze a basic Half Wave Rectifier circuit using PSpice software. This is a perfect guide for beginners in electronics who want to learn circuit simulation. What You'll Learn in This Video: How to create a new project in PSpice (OrCAD Cadence) How to place components (AC Voltage Source, Diode, Resistor, Ground) How to wire the circuit and set up the simulation profile for Transient Analysis How to run the simulation and probe the input and output waveforms How to analyze the output voltage and understand the effect of the diode We'll cover everything from setting up the circuit schematic to running the simulation and interpreting the results. You'll see how AC voltage is converted into pulsating DC voltage and understand the role of the diode. Voltage Source: VSIN (VAC = 12V, Freq = 1k) Diode: D1N4002 (Ideal Diode can also be used) Load Resistor: R = 1kΩ 📊 Simulation Profile: Analysis Type: Time Domain (Transient) Run to time: 2ms (To view 2-3 cycles of 50Hz) Start saving data after: 0 📖 Related Videos: Installing PSpice Student Version: [   • "Pspices" How to install PSPICE 9.1 studen...  ] 🔔 Subscribe for more tutorials on circuit simulation, electronics, and PSpice! Hit the bell icon to get notified whenever we upload a new video. #PSpice #HalfWaveRectifier #Electronics #Engineering #Simulation #Tutorial #BeginnersGuide #OrCAD #Diode #CircuitSimulation #ElectricalEngineering #ECE Disclaimer: This video uses the student version of PSpice, which is free for educational use.
