Branch Current Analysis & Nodal Voltage Analysis Explained Using a Simple Example (With Experiment)

In this recording of a live-streamed lecture, I give a brief overview over circuit calculation and network analysis methods. We then take a more detailed look onto branch current analysis and nodal voltage analysis using a simple example. In this example the equivalent resistance or total resistance of a resistive circuit consisting of five resistors shall be determined. Slides: https://cloud.ovgu.de/s/RikYZ5qDNJ22cxn Notes for branch current analysis: https://cloud.ovgu.de/s/qTpjZRwFkk9NKGG Notes for nodal voltage analysis: https://cloud.ovgu.de/s/jiG6D3XttWkkw7o Octave commands: R_1=1e3 R_2=2e3 R_3=1e3 R_4=1e3 R_5=3e3 matrix=[-1 0 -1 0 0 1;0 1 0 1 0 -1;1 -1 0 0 1 0;R_1 R_2 0 0 0 0;-R_1 0 R_3 0 R_5 0;0 -R_2 0 R_4 -R_5 0] V_s=1 right_side=[0;0;0;V_s;0;0] currents=inv(matrix)*right_side R_AB=V_s/currents(6) G_1=1/R_1 G_2=1/R_2 G_3=1/R_3 G_4=1/R_4 I_s=1 nodal_matrix=[G_1+G_3 -G_1 -G_3;-G_1 G_1+G_2 0;-G_3 0 G_3+G_4] I_s_vector=[1;0;0] V_nodal=inv(nodal_matrix)*I_s_vector R_AB=V_nodal(1)/1 G_5=1/R_5 nodal_matrix_new=[G_1+G_3 -G_1 -G_3;-G_1 G_1+G_2+G_5 -G_5;-G_3 -G_5 G_3+G_4+G_5] V_nodal_new=inv(nodal_matrix_new)*I_s_vector R_AB_new=V_nodal_new(1)/1 Chapter marks: 00:00:00 Introduction 00:12:30 Network structure 00:17:26 Branch current analysis 00:36:06 Solution in GNU Octave 00:42:39 Experiment for comparison 00:48:23 Nodal voltage analysis 01:04:15 Solution in GNU Octave 01:11:17 Quiz questions
