Thermecro Solar Heater - Installation Video - Updated

A step by step video guide on how to install your Thermecro solar heater, interface valve and controller. 0:14 - What’s in the box 0:17 - Adding the hinge brackets to the frame straights 0:35 - Positioning the upper and lower manifolds 0:48 - Positioning and fixing the frame straights to the upper manifold 1:27 - Attaching the frame straights to the lower manifold 1:52 - Attaching the feet to the two outer frame straights 2:04 - Attaching the feet to the two curved legs 2:27 - Attaching the curved legs to the outer frame straights 2:37 - Attaching the telescopic arms 3:01 - Attaching the cross brace 3:22 - Adjusting the position and angle of the frame 3:47 - Lifting the frame to its upright position 4:01 - Tighten all attachments EVACUATED TUBES 4:11 - Unboxing the evacuated tubes 4:38 - Connecting the evacuated tubes to the upper and lower manifolds 5:36 - Attaching the female adapters to the end cap 6:03 - Connecting the inlet and outlet PEX pipes 6:11 - Connect the evacuated tube with the NTC temperature sensor POOL INTERFACE VALVE (IMPORTANT UPDATE - It is recommended to position the Electronic ball valve on the inlet pipe to prevent any unnecessary pressure entering the solar rack. Please follow the illustration on the video or refer to the latest Thermecro manual). 6:22 - Preparing the pipework for the pool interface valve 6:46 - Preparing and attaching the female and male adapters to the pool interface valve 7:07 - Inserting the O-ring and connecting the pool interface valve CONTROLLER 7:26 - Wire connection for the power supply 7:44 - Wire connection for the electronic ball valve output 7:58 - Wire connection for the solar array NTC temp sensor 8:11 - Wire connection for the pool interface NTC temp sensor 8:29 - Re-attaching the cover to the controller 8:34 - Connecting the inlet and outlet PEX pipes to the interface valve
