Tricky RC Circuit With Multiple Capacitors and Multiple Resistors

A circuit with two capacitors and two resistors is first charged with the switch closed at (a), and we have to find the charge on C2 after 70 micro seconds. Then the switch is opened at (a) and closed at (b) and we need to find the change on C2 after another 20 micro seconds. Setting up the RC charging and discharging equation is complicated because there are multiple capacitors and resistors, and we need to be careful to only include the elements that are in the active circuit in each case. Here's a related video demonstrating why charges in series will always have the same charge difference (also called "change in charge", or "delta Q"):    • Capacitors Charging in Series With an Init...   For more details about how I help students pass physics, including free subscriber-only access to free downloadable resources and an online library of E&M physics problems organized by category, visit: http://www.redmondphysicstutoring.com.... Good luck! Scott
