RayKol AP300 Automated Liquid Handling System | Precision Liquid Processing for Labs скачать в хорошем качестве

RayKol AP300 Automated Liquid Handling System | Precision Liquid Processing for Labs

Introducing the RayKol AP300 Automated Liquid Handling System – your solution for efficient and precise liquid sample preparation. Designed for laboratories in food, environmental, pharmaceutical, and chemical analysis, the AP300 automates critical steps to enhance accuracy, reproducibility, and throughput. This versatile system is ideal for tasks such as sample dilution, transfer, volumetric determination, standard solution preparation, calibration curve generation, and quantitative addition of standards, supporting complex multi-step dilutions. --- KEY FEATURES & TECHNICAL SPECIFICATIONS: ► PRECISION LIQUID HANDLING: Equipped with 3 high-precision syringe pumps (100μL, 1000μL, 10mL) for independent drive and broad volume range. Supports single-step liquid transfer volumes from 10μL to 1000μL. Customizable sample needle material (stainless steel, PTFE, piercing needle) for various sample types. ► VERSATILE SAMPLE & REAGENT COMPATIBILITY: Accommodates a wide range of containers: 2mL vials, 20-40mL reagent bottles, 15-100mL centrifuge tubes, 10-25mL volumetric flasks, and more (customizable). Maximum capacity for 288 vials. External diluent source switched via a rotary 8-way valve, drawing directly from 500mL solvent bottles. ► ADVANCED AUTOMATION & EFFICIENCY: Automatic lid opening/closing for various tube types (2mL, 15mL, 50mL, 100mL). Independent cleaning stations (≥4) with overflow and drying functions for the sampling needle. Built-in automatic vortex mixing (optional, 1-300rpm) for up to 72 vials. Dual Z-axis for precise bottle height positioning (top/bottom detection). Automatic piercing and de-capping function. ► CONTROL & SOFTWARE: Intuitive graphical operation software with guided method setup. Features for automated generation of intermediate solutions for multi-step dilutions. Supports standard curve dilution (≥10 points) and mixed standard preparation with up to 20 intermediate solutions. Built-in method packages for food, water quality, and soil analysis (≥20 methods). ► OPERATIONAL EXCELLENCE: Visual design with four-sided sealing and transparent front/side panels for easy monitoring. Integrated lighting system and dual alarms (software + indicator lights) for operational safety. Real-time monitoring of steps, consumed volumes, and traceable logs for data security. Supports Windows 7/8/10 systems for control via PC or tablet. ► REFRIGERATED & CONTROLLED ENVIRONMENT: Semiconductor refrigeration module for temperature-controlled positions (≥210 positions, down to 10°C below room temp). --- APPLICATIONS: Ideal for sample dilution, transfer, volumetric determination, standard solution preparation, calibration curve generation, and quantitative addition of standards. --- Learn More & Get a Quote: Visit our official website: www.raykolgroup.com For sales inquiries, contact us at: info@raykolgroup.com --- #AutomatedLiquidHandling #LabAutomation #SamplePreparation #LiquidDispensing #LabWorkflow #ScientificInstruments #ChemicalAnalysis #FoodAnalysis #PharmaLab #environmentaltesting
