DENKO OIL BDV TEST SET / TRANSFORMER OIL TESTING KIT 100 KV AUTOMATIC DEMONSTRATION

© ALL RIGHTS RESERVED. H.K ENTERPRISES, NEW DELHI. FOR ORDERS AND ENQUIRIES : H.K. ENTERPRRISES (DENKO) Email: hkdelco@gmail.com Cell: +91 9958597966, 9871604580 www.denko.co.in DENKO Oil Test set is ideal for speedy and accurate testing of DI-i-electric strength of transformer and circuit breaker oil under test room condition in accordance with IS:6792-1972 for oil testing Input : 230 Volts, Single Phase, 50 Hz, AC. Output : Continuously variable from 0 to 50 Kv or 0 to 60 Kv, or 0 to 100 Kv,' Capacity: 1000 VA(1KVA ) Nature of cooling: The transformer will be epoxy resin cast type air-cooled type Duty: the oil test set will be designed for"intermittent" rating General arrangement: The set will be comprising of the H.T. transformer, control circuity Test cell with electrode & gauge and will be supplied in portable air cooled sheet metal casing with powder coating of control cubical & H.T. transformer One continuously variable Auto-Transformer for smooth variation of out put voltage or Motorized operation using push button Beside the ON/OFF switch, fast acting Automatic tripping mechanism for protection of H.T Transformer gains to overloading on flash over One zero start inter locking device Three pilot lamps to indicate mains 'ON' , H.T. circuit 'ON' & H.T. circuit 'OFF' One input supply cable with 3- pin plug One memory effect volt meter show the break down voltage even after the high voltage circuit stripped off Mode of operation: sets are available either in manual or in motor; operated mode. Besides, motorized auto-transformer regulator can be operated in manual through switch H.T. Transformer: high voltage transformer ration is 230v/ 50 Kv or 60 Kv or 100Kv or 120Kv with center tap HV winding earthed Test vessel: The test vessel (Oil Cell)fitted with two brass spheres of diameter between12.7 to 13mm, placed at a distance of 4 mm or 2.5mm on sides of test vessel made from non-absorbent insulating material Cover: Sets will be provided with transfer and high impact acrylic sheet cover for covering the H.T. side with suitable inter-locking device.
